96
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH12QB-K3DNA6D/O GWH18QD-K3DNA6E/O
Product Code CB427W04701 CB427W06400
1 Left Side Plate 01303200P 01303200P 1
2 Fan Motor 15013085 15013085 1
3 Motor Support 01703136 01703136 1
4 Condenser Assy 01100200658 011002000015 1
5 Top Cover Sub-Assy 01253081 01253081 1
6 Rear Grill 01475014 01475014 1
7 Clapboard Sub-Assy 01233180 01233180 1
8 Compressor and Fittings 00103364 00103388 1
9 Discharge Tube 03500800859 035008000191 1
10 Compressor Gasket / / /
11 Inhalation Tube Sub-assy 03001000432 03001000432 1
12 Big Handle 2623343106 2623343106 1
13 Cut off Valve 07130239 07130239 1
14
Cut off Valve 07130239 07130239 1
15 Valve Support 0171314201P 0171314201P 1
16 Front Grill 22413047 22413047 1
17 Cabinet 01433033P 01433033P 1
18 Axial Flow Fan 10333011 10333011 1
19 Chassis Sub-assy 017000000091P 017000000086P 1
20 Electric Box Assy 100002000323 100002000019 1
21 Electric Box 20113032 20113032 1
22 Main Board 30138001122 30138001137 1
23 Reactor 43130184 43130184 1
24 Wire Clamp 71010103 71010103 1
25 Terminal Board 42010313 42010313 1
To Next Page
