Please make sure the inverter is installed at the right place.The inverter can’t
install close to trunk。
5.3 Mounting the Inverter
5.3.1 Mounting the Inverter with bracket
In order to avoid electrical shock or other injury, inspect existing
electronic or plumbing installations before drilling holes.
Fix the mounting bracket as the figure shows. Do not make the screws to be
flush to the wall. Instead, leave 2 to 4mm exposed.
