Grundfos MGE Series User Manual

English (GB)
45
10.35 ""Run start-up guide""
This menu is only available in the advanced control
panel.
The startup guide automatically starts when you start
the motor for the first time.
You can always run the startup guide later via this
menu.
The startup guide guides you through the general
settings of the motor.
• ""Language"". See section 10.24 ""Language"".
• ""Select date format"".*
See section 10.25 "Date and time" (""Set date
and time"").
• ""Set date"".*
See section 10.25 "Date and time" (""Set date
and time"").
• ""Select time format"".*
See section 10.25 "Date and time" (""Set date
and time"").
• ""Set time"".*
See section 10.25 "Date and time" (""Set date
and time"").
• Setting the motor
– ""Go to Home""
– ""Run with Constant curve""/""Run with
Constant pressure"".
See section 10.4 "Control mode".
– ""Go to "Assisted pump setup""".
See section 10.39 ""Assisted pump setup""
(Assisted motor setup).
– ""Return to factory settings"".
* Applies only for motors fitted with an advanced
functional module, type FM 300. See section
15. Identification of functional module.
10.36 ""Alarm log""
This menu contains a list of logged alarms from the
product. The log shows the name of the alarm, when
the alarm occurred and when it was reset.
10.37 ""Warning log""
This menu contains a list of logged warnings from
the product. The log shows the name of the warning,
when the warning occurred and when it was reset.
10.38 ""Assist""
This menu consist of a number of different assist
functions which are small guides that take you
through the steps needed to set the motor.
10.39 ""Assisted pump setup"" (Assisted
motor setup)
This menu guides you through the following:
Setting the motor
• Selection of control mode. See page 32.
• Configuration of feedback sensors.
• Adjusting the setpoint. See page 32.
• "Controller settings". See page 37.
• Summary of settings.
Example of how to use the ""Assisted pump
setup"" for setting the motor to "Constant other
value"
Grundfos GO
1. Open the ""Assist"" menu.
2. Select ""Assisted pump setup"".
3. Select control mode "Constant other value"
(""Const. other val."").
4. Read the description for this control mode.
5. Select which analog input to use as sensor input.
6. Select sensor function "Other parameter".
7. Select electrical input signal according to the
sensor specifications.
8. Select measuring unit according to the sensor
specifications.
9. Set the minimum and maximum sensor range
values according to the sensor specifications.
10. Set the desired setpoint.
11. Set the gain and integral time of the controller.
See section 10.11 "Controller" (""Controller
settings"").
12. Type the desired motor name.
13. Check the summary of settings and confirm
them.
