Haier HLP24E Service Manual

Order No. TL1001S003V1.1
Rev.
Service Manual
Issue
6-2-2
6-2-3
17
Switch on the power .Push
the START button
Confirm the action sound
of the water inlet valve ?
There is sound
Remove the foreign materials of the water
inlet valve filter screen or raise the water
pressure to 0.03Mpa-1Mpa before use
There is no sound
No water filling
Measure the voltage
of the two ends of the water
inlet valve ?
There is voltage
There is voltage
Replace the water inlet valve.
There is no voltage
Replace the computer sequencer
Replace the wire unit
Replace the wire unit
At this time please check if the water inlet valve
works normally.
There is no voltage
Measure the voltage
of the two ends of the computer
sequencer?
No rotation in washing (or rotate to one direction only)
Start the test without water.
Enter no-water washing.
Check the action of the motor.
Acts
Please check the transmission
system carefully.
If it is normal of the bearing part
locking the clutch.
No exist
Measure the voltage
of the two ends of the motor
Exist
Replace the
capacitor
Replace the motor
Yes
Yes
At this time please check if the
capacitor and motor works normally.
Replace the computer sequencer.
Replace the
wire unit.
Exist
No exist
Measure the voltage
of the two ends of output of
the computer sequencer.
Please check
the reason.
If the motor overheat
protector acts?
No
No
If the capacitor has brocken
circuit or short circuit?
No exist

Haier HLP24E Specifications

General

Door hinge	Up
Drum volume	42.4 L
Control type	Buttons
Display type	LED
Loading type	Top-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption washing per cycle	- kWh
Drum capacity	- kg
Spin-drying class	-
Maximum spin speed	800 RPM
Noise level (spin)	- dB
Load balancing system	No
Number of washing programs	3

Weight and Dimensions

Depth	510 mm
Width	500 mm
Height	901.7 mm
Weight	19504 g
