Haier HLP24E Service Manual

Do not decompose, repair or alter the
machine by yourself.
Do not put any hot or heavy items (such
as the kettle with hot water ) on the
washing machine.
Do not wash laundries with volatile
materials (such as thinner, petrol etc.)
The children shall not approach
the working washing machine.
Keep the machine away from direct
sunlight and heat source like the heater.
Do not stretch hands into the working
machine. It is dangerous even if the
rotation is slow. Take special care of
the children.
Petrol
Thinn
er
Please check if the water faucet is open, and if the connection of the
water inlet pipe is proper.
It is suggested to use foamless washing powder.
Please don t use the washer in the environment below 0 C; if the washer
has been stored below 0 C, please be sure to ensure the washer is placed
under the room temperature more than 2 hours and then use otherwise
the washing effects may be lowered or the washer may be damaged.
7
Order No. TL1001S004V0
Rev.
Service Manual
Issue
3-2.Warning and Cautions

Haier HLP24E Specifications

General

Door hinge	Up
Drum volume	42.4 L
Control type	Buttons
Display type	LED
Loading type	Top-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption washing per cycle	- kWh
Drum capacity	- kg
Spin-drying class	-
Maximum spin speed	800 RPM
Noise level (spin)	- dB
Load balancing system	No
Number of washing programs	3

Weight and Dimensions

Depth	510 mm
Width	500 mm
Height	901.7 mm
Weight	19504 g
