Haier HLP24E Service Manual

21
9. Brake time out
Is the brake moment of the retarder
lower than 6N.m?
Adjust the brake moment.
Is the reset spring of the retarder loose?
Adjust the reset spring.
Is the gap between the connecting arm block
and the brake arm of retarder less
than 0.8mm?
Check if the pawl can leave the ratchet for 2mm
up during spinning. If not, adjust the position of
the brake arm.
Replace the retarder.
Yes
No
Yes
Yes
No
No
6-2-10
Se r vice Manual
Model No: TL1001S003V1.1
Issue
Re v.

Haier HLP24E Specifications

General

Door hinge	Up
Drum volume	42.4 L
Control type	Buttons
Display type	LED
Loading type	Top-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption washing per cycle	- kWh
Drum capacity	- kg
Spin-drying class	-
Maximum spin speed	800 RPM
Noise level (spin)	- dB
Load balancing system	No
Number of washing programs	3

Weight and Dimensions

Depth	510 mm
Width	500 mm
Height	901.7 mm
Weight	19504 g
