Order No. TL1001S003V1.1
Rev.
Service Manual
Issue
6-2-4
6-2-5
18
No draining
Set rinse or spin start
the machine.
Check if the drain motor acts?
Roll up normally
Check the drain system like the
drain pump etc.
Measure the voltage
of the two ends of the output
of the computer
sequencer.
Exist
Exist
Measure the voltage
of the two ends of the
drain motor.
No
No Exist
Check the drain motor.
Check the wire unit.
At this time please check if the
water inlet valve is well.
Replace the computer sequencer.
No Exist
Yes
Yes
Yes
Yes
Yes
Keep filling water
Open the water faucet
without switching on the power.
Replace the water inlet valve.
Replace the computer sequencer.
Replace the wire unit.
It weaks gas.Please check and
repair the gas guide system.
If the water can fill into the
water inlet valve.
Switch on the power.Do not
push the START button.
Replace the water level switch.
Check if the gas guide
system is blocked?
If the water can fill into the
water inlet valve.
Check if the wire
connecting the computer board to
the water level sensor is bad?
Select 1 to 2 water level
and start the machine to
check if the gas cell has
water.
Blow form the connecting pipe to the
water level sensor and gas cell to see
if there is blocked.
Clear various factors like
the foreign materials.
Please smear 801 glue in installation
of the connecting pipe.
Please smear 801 glue in installation
of the gas cell cover.
To Next Page
