Haier LT19M1CW User Manual

IMPORTANT: When drilling into
walls always check that there
are no hidden wires or pipes etc.
Make sure that the screws and
wall plugs supplied are suitable
for supporting the unit. Consult
a qualified tradesperson if you
are not sure.
NOTE: It would be useful to ask
someone to help you at this
stage.
WALL MOUNTING
NOTES:
- Please read the important safety
instructions before use.
1. Put the unit face down on a safe,
flat surface that is covered by a
smooth cloth.
See fig. 4 and 5.
Stand
fig. 4
Screws
WALL MOUNTING (Optional)
fig. 6
fig. 5
Stand
2. Unscrew the screws of the stand.
Then remove the Stand.
See fig. 4 - 6.
HD Ready Digital LCDTV User Manual
8

Haier LT19M1CW Specifications

General

HD type	WXGA
Display diagonal	19 \
Display brightness	250 cd/m²
Display resolution	1440 x 900 pixels
Display technology	LCD
Native aspect ratio	16:9
Viewing angle, vertical	170 °
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Supported graphics resolutions	1440 x 900 (WXGA+)
Manual	Yes
Package weight	5000 g
RS-232 ports	0
SCART ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Common interface Plus (CI+)	No
Number of OSD languages	14
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE
Product color	Black
LED indicators	Y, Stand-by
Panel mounting interface	100 x 100 mm
AC input voltage	110 - 230 V
Power consumption (standby)	1 W
Power consumption (typical)	45 W
RMS rated power	6 W
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Depth (with stand)	95 mm
Width (with stand)	455 mm
Height (with stand)	308 mm
Weight (with stand)	4000 g
