Haier LT19M1CW User Manual

Know Your Machine ......................................................................................... 3
Remote Control ................................................................................................ 6
Wall Mounting.................................................................................................... 8
Antenna Connection ......................................................................................... 10
Tuning Menu Options ...................................................................................... 11
Other Connections ............................................................................................ 13
Basic Operation ................................................................................................ 18
Menu Operation ................................................................................................ 22
Teletext .............................................................................................................. 32
Common Interface Module ............................................................................... 34
Troubleshooting ............................................................................................... 36
Specifications .................................................................................................. 37
CONTENTS
HD Ready Digital LCDTV User Manual
NOTE: This LCD cabinet drawing is a sample and may not depict
your actual LCD
cabinet design.
2

Haier LT19M1CW Specifications

General

HD type	WXGA
Display diagonal	19 \
Display brightness	250 cd/m²
Display resolution	1440 x 900 pixels
Display technology	LCD
Native aspect ratio	16:9
Viewing angle, vertical	170 °
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	160 °
Supported graphics resolutions	1440 x 900 (WXGA+)
Manual	Yes
Package weight	5000 g
RS-232 ports	0
SCART ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Common interface Plus (CI+)	No
Number of OSD languages	14
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, ITA, NOR, POL, POR, RUS, SWE
Product color	Black
LED indicators	Y, Stand-by
Panel mounting interface	100 x 100 mm
AC input voltage	110 - 230 V
Power consumption (standby)	1 W
Power consumption (typical)	45 W
RMS rated power	6 W
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-T

Weight and Dimensions

Depth (with stand)	95 mm
Width (with stand)	455 mm
Height (with stand)	308 mm
Weight (with stand)	4000 g
