Hardi FOAM MARKER Standard User Manual

23
HARDI
®
FOAM MARKER STANDARD VERSION
1. Locate the mounting holes for the Compressor Box at the rear of the
sprayer (Fig. 21).
2. Mount the Compressor Box to the frame using the 6mm nuts supplied.
Note: Use power extension cable #26001903 to connect the Compressor
Box to the power supply cable.
8.5 New Navigator 575, 1100
HOLES FOR
COMPRESSOR
Fig. 21
