Harman JBL AURA WALL MOUNT STEREO User Manual

Fig. A
Fig. B
Fig. C
3. Attach the AURA with 4 fasteners. Push the cover gently onto the AURA and press firmly as shown in Fig. C.
6 MOUNTING
10
2. Cut out opening size as shown in Fig. B.
11
1
4 "
2
3
8 "
2
1
16 "
10
5
8 "
cut out
3
3
4 "
cut out
2
1
2 "
(Allow for connections)
1. Predrill 4 mounting holes as shown in Fig.A.
Select fasteners (not included) suitable for the mounting materials.
5
1
2 "

Harman JBL AURA WALL MOUNT STEREO Specifications

General

Brand	Harman
Model	JBL AURA WALL MOUNT STEREO
Category	Stereo System
Language	English
