Harman JBL AURA WALL MOUNT STEREO User Manual

NOTE: Before connecting, disconnect power to AURA and the powered subwoofer.
NOTE: Subwoofer will play with ZONE "A" only.
R
L
Red
White
Red
White
R
L
1. Connect the audio cable as above, connect the REM OUT wire to the subwoofer REMOTE IN wire, if equipped.
2. Power on the AURA Wall Mount Stereo.
3. Play the music as usual and set the desired volume.
9 ADDING OPTIONAL EXTERNAL POWERED SUBWOOFER
REM OUT
EXTERNAL
SUBWOOFER
REMOTE
IN
REAR PANEL
(if equipped)
12
Refer to powered subwoofer instruction or user
manual for further instructions.
(not supplied)
