3 PRODUCT OVERVIEW
Controls and Features
Connectors
USB
AUX 1 HD MI IN
Reset
ANTENNA
EXT IR
OPTICAL IN
HDMI OUT
(ARC)
AUX 2
R L
REM OUT
EXTERNAL
SUBWOOFER
GRAY-B RIGHT +
GRAY/BLAC K- B RIGHT-
BLACK-P OWER GN D
RED-POWER IN 12V+
15A FUSE
GREEN-C L EFT +
GREEN/B LACK- C LEFT-
VIOLET-C R IGHT+
BLUE/BL ACK-A RIGH T-
BLUE-A RIG HT +
ORANGE/ BLACK -A LE FT-
VIOLET/ BLACK -C RIGH T-
SPEAKER W IRE SOC KET
WHITE-B L EFT+
WHITE/B LACK- B LEFT-
ORANGE- A LEF T+
1 2 3 4 5 6 7 8 9 10 11 12 13
14
15
16 17 18
19 20 21 22 23 24 25 26
1. Source Button
2. Audio Zone A
3. Audio Zone B
4. Audio Zone C
5. Pair Button
6. Remote Sensor
7. AURA Ring
8. Light Sensor for Display Brightness
9. Play/Pause Button
10. Previous Button
11. Next Button
12. Volume Down Button
13. Volume Up Button
14. Power Button
15. Display
16. USB Port
17. AUX 1 Jack/Reset
18. HDMI IN Port
19. Antenna Connector
20. HDMI OUT (ARC) Port
21. AUX 2 Jacks
22. External IR Jack
23. OPTICAL IN Jack
24. REM OUT Cable (Amp. Pwr. Trigger)
25. External Subwoofer Jacks
26. Speaker/Power Wire Sockets
