Harris APEX User Manual

APEX™ Exciter Incorporating FLO™ Technology
Parts List
2604s600.fm
03/08/07 888-2604-001 Page: 6-1
WARNING: Disconnect primary power prior to servicing.
6Parts List
Table 6-1 EXCITER, APEX FLO QUALCOMM, UHF - 992 9943 101 (K)
Harris PN Description Qty UM Reference Designators
026 6010 002 GROMMET STRIP, 0.090 1 FT
200000000000000290 PARTITION, FAN 1 EA
250 0597 000 CABLE, FFC 18C 0.5MM 3” LG 1 EA
250 0612 000 CABLE ASSY, SMA MALE/FEMALE 1 EA
250 0613 000 CABLE ASSY,SMA MALE/FEMALE 1 EA
250 0614 000 CABLE ASSY, SMA MALE/SMA MALE 1 EA
256 0029 000 *CABLE ASSY, H FL/SMA SERIES 12” 1 EA
302 0780 000 SCREW, PHMS, 6-32 X 3/8 0 EA
358 0420 000 SPACER, ROLLED 1/4 L 4 EA
358 1214 000 SCREWLOCK, M/F 4-40X3/16” 2 EA
358 3434 000 TY-RAP MTG BASE.316” TIE 2 EA
358 3579 000 SLIDES, DRAWER 1 PR
398 0496 000 FUSE, SLOW CART 4A 250V 2 EA
424 0012 000 GROMMET 1/4 MTG DIA 1 EA
430 0314 000 FAN, RADIAL, 12V 38CFM 127MM 1 EA
448 1082 000 GASKET, EMI/RFI SHIELDING, 14 FT
484 0446 000 *FILTER, RFI POWER LINE ENTRY 1 EA
484 0557 000 FILTER, LOWPASS, 750MHZ 1 EA LPF001
556 0170 000 ATTEN, FIXED, 5DB 2W SMA 3 EA AT001,AT002,AT003
610 1253 000 MALE CONNECTOR, 4C, 1 EA
628 0014 000 ADAPTOR, SMA-JACK TO BNC-JACK 1 EA
646 0665 000 INSPECTION LABEL 1 EA
646 1487 000 NAMEPLATE PATENT, GENERIC 1 EA
646 1699 000 OVERLAY, APEX 1 EA
700 1422 019 LOAD, 50 OHM, 1/2W 1 EA A2J3
736 0356 000 POWER SUPPLY, 150W, 4 OUTPUTS 1 EA PS1
746 0327 000 LCD DISPLAY, 1/4 VGA COLOR 1 EA
813 4999 032 STDOFF 6-32X1-1/2 1/4 HEX 4 EA
843 5552 007 FAMILY TREE EXCITER 0 DWG
843 5552 026 WIRING DIAGRAM, APEX EXCITER (QUALCOMM)0 DWG
917 2551 004 CABLE PKG, APEX 1 EA
917 2551 008 CABLE PKG, APEX ECITER (QUALCOMM PROJECT)1 EA
922 1330 001 COVER, DISPLAY 1 EA
939 9369 004 LABEL, APEX OUTLINE 2 EA
943 5418 008 DIVIDER, CENTER 1 EA
943 5418 009 CHASSIS, LEFT SIDE, REAR 1 EA
943 5552 005 CHASSIS, MINI 1 EA
943 5552 011 COVER, SAFETY 1 EA
943 5552 012 PLATE, PS MTG 1 EA
943 5552 017 ANGLES, SAFETY COVER MTG 2 EA
943 5552 020 CHASSIS, RIGHT SIDE/ FRONT 1 EA
943 5552 021 COVER, CHASSIS 2 EA
943 5552 022 DIVIDER, SAFETY COVER 1 EA
943 5552 023 PLATE, CABLE SHIELD 1 EA
943 5585 018 PLATE, 9 PIN D-SHELL 1 EA
943 9153 013 LABEL, COMPONENT OUTLINE APEX EXCITER 2 EA
992 9995 002 *PWA, D/A CONVERTER 1 EA A12
992 9995 004 *PWA, FRONT PANEL 1 EA A10
