106 Fixed Cycles: Tapping / Thread Milling
4.1 Basics
4.1 Basics
Overview
The TNC offers 8 cycles for all types of threading operations:
Cycle Soft key Page
206 TAPPING NEW
With a floating tap holder, with automatic
pre-positioning, 2nd setup clearance
Page 107
207 RIGID TAPPING NEW
Without a floating tap holder, with
automatic pre-positioning, 2nd setup
clearance
Page 109
209 TAPPING W/ CHIP BREAKING
Without a floating tap holder, with
automatic pre-positioning, 2nd setup
clearance, chip breaking
Page 112
262 THREAD MILLING
Cycle for milling a thread in pre-drilled
material
Page 117
263 THREAD MILLING/CNTSNKG
Cycle for milling a thread in pre-drilled
material and machining a countersunk
chamfer
Page 120
264 THREAD DRILLING/MILLING
Cycle for drilling into the solid material
with subsequent milling of the thread
with a tool
Page 124
265 HEL.THREAD DRILLING/MILLING
Cycle for milling the thread into the solid
material
Page 128
267 OUTSIDE THREAD MILLING
Cycle for milling an external thread and
machining a countersunk chamfer
Page 128
