2.3.2 I/O Interfaces Description
The interfaces description of DS-2CZ21X2P(N) are as follows:
Table 2-2 DS-2CZ21X2P(N) interfaces description
Pin No.
Name
Description
ZOOM
(Wire Control Interface)
Lens Zoom Adjustment
COM
(Wire Control Interface)
Common Interface for the Pins
No. 1 and No. 3
FOCUS
(Wire Control Interface)
Focus Adjustment
IN/GND
Trigger Interface of the
Day/Night switching/GND
Interface
OUT/COM
Alarm Output/Common
Interface
