Network Speed Dome User Manual
Threshold: Range [0-10s], the threshold for the time of the object staying in
the region. If you set the value as 0, alarm is triggered immediately after the
object entering the region.
Sensitivity: Range [1-100]. The value of the sensitivity defines the size of the
object which can trigger the alarm, when the sensitivity is high, a very small
object can trigger the alarm.
Detection Target: You can select human, vehicle, or all (human &vehicle) as
the detection target from the dropdown list. If Human is selected, only
human beings will be identified as detection objects and as well as Vehicle.
6. Click tab to enter the arming schedule setting interface. The
time schedule configuration is the same as the settings of the arming schedule
for motion detection. Refer to Step 2 in Section 5.2.1 Configuring Motion
Detection.
7. Click tab to select the linkage method taken for the video loss
alarm, Notify surveillance center, send email, trigger channel, smart tracking and
trigger alarm output are selectable. Please refer to Step 3 in Section 5.2.1
Configuring Motion Detection.
8. Click to save the settings.
5.3.4 Configuring Line Crossing Detection
The virtual plane detection can be adopted for the intrusion detection. Once the
virtual plane is detected being traversed according to the configured direction, a set
of alarm action is triggered.
Steps:
1. Enter the Line Crossing Detection interface:
Configuration >Event > Smart Event > Line Crossing Detection
2. Check the Enable checkbox to enable the line crossing detection function.
3. Select the Line in dropdown list to configure.
4. The event triggered and park action related PTZ movement will be locked for 180
seconds after you enter the line crossing detection interface. Optionally, you can
To Next Page
