5. Click the dropdown list of Detection Target to select the target.
6. Enable rules: Check the Enable checkbox of each rule in the rule list to enable the rule.
7. Click to save the settings.
6.4.4 Region Exiting
Purpose:
This function can be used for detecting people, vehicles and objects exiting the pre-defined
region. The alarm will be triggered if the rule is broken.
Steps:
1. Create new rule: Click on the button to add a new rule.
2. Select rule type: Click the dropdown menu and select Region Exiting as the rule type.
3. Configure the rule area:
Click on the tool bar of the live view panel. Click the mouse on the live view panel.
Right click the mouse to finish drawing.
Figure 6-12 Draw Area
4. Configure the filtering size: for details, see step 3 in section 6.4.1 Line Crossing.
5. Click the dropdown list of Detection Target to select the target.
To Next Page
