Thermal & Optical Bi-spectrum PTZ Network Camera User Manual
24
5.2.1 Set a Detection Scene
Multiple detection scenes are supported for both channels. You can create scenes and set the
tracking parameters for better target monitoring performance. The settings may vary according to
different camera models.
Steps
1. Go to Configuration → Ship Detection.
2. Click Scene Configuration and New Scene to create one or more scenes.
3. Select a numbered scene from the navigation bar on the left and enter a Scene Name.
Note
If you want to show the name on the image, check Display Scene Name.
4. Select a Channel No. from the drop down list.
5. Set the Scene Ratio by controlling the zoom in/out buttons.
6. Check Track to enable the target tracking function for the scene.
7. Optional: Check Limited Tracking and set the auto tracking range.
The camera channel tracks a target only within the set auto tracking range.
1) Control the PTZ buttons to a desired scene and click Set Up Limit to save the position as the
scene's upper boundary.
2) Repeat to set the left, right and lower boundaries of the scene.
Tracking Duration
Set the duration of tracking. If the value is selected as 0, the tracking duration will not be
limited.
Zooming Ratio
It is the zoomed-in level when the camera channel is tracking a target.
Go to Configuration → Ship Detection → Zooming Ratio, select a scene from the drop-
down list, and control the zoom in/out buttons to get a desired zooming level, and save the
settings.
Post-tracking
Set the duration of automatic tracking of the target after it stops.
Go to Configuration → VCA → Advanced Configuration, and set parameter.
8. Click Save.
5.2.2 Set Ship Flow Detection
After enabling this function, the device will trigger an alarm if ships enter or exit the set regions,
and will count the ships that pass across the alarm line for the first time.
Steps
1. Go to Configuration → Ship Detection → Scene Configuration → Scene x → Rule.
