You can manually set the working shifts for the channels.
1. Select the Polling Mode as Manual.
2. Select Optical Channel or Thermal Channel for the drop-down
list.
3. Drag to draw time bars on the schedule. Click on the drawn bar to
adjust the time and the channel.
Note
The schedule for the channels can not overlap.
3. Click Save.
6.4 Advanced Configuration
Go to Configuration → VCA → Advanced Configurationand configure the parameters.
Detection Parameters
Detection Sensitivity
The higher the sensitivity is, the easier the target will be detected.
Background Update Rate
if a detected target remains in the monitoring scene for a certain time, the system will count the
target as the background automatically. The greater the value is, the faster the target will be
counted as the background.
Minimum Target Size
The system will filter out the object smaller than the minimum target size.
Displacement Constraint for Target Generation
The higher the value is, the slower the target is generated, and the higher accuracy the analysis
will get.
Optical-axis Movement
Check the function when the target moves in the direction of camera's optical -axis.
When the target is far from the device and the movement is not clear, enable this function to
check the move direction.
Single Alarm
The system only sends alarm once for one target triggering. Otherwise, the alarm will be
triggered continuously until the target disappears.
