HIKVISION DS-7104NI-Q1 User Manual

2. Click Patrol.
3. Select a desired patrol.
4. Click Set.
5. Click
.
6.
Congure key point parameters, such as the key point No., duraon of staying for one key point
and speed of patrol. The key point is corresponding to the preset. The preset number
determines the order at which the PTZ will follow while cycling through the patrol.
Duraon
refers to the me span to stay at the corresponding key point. Speed denes the speed at which
the PTZ will move from one key point to the next.
Figure 2-4 Patrol Sengs
7. Click Apply.
What to do next
Select a patrol and click Call to call it. The PTZ camera will move according the predened patrol
path.
Figure 2-5 Call Patrol
2.2.5 Customize Paern
A paern records the movement path and dwell me in a certain posion. When you call a
paern, the PTZ camera will move according to the recorded path.
Steps
1. Preview a camera in live view and click on shortcut menu.
2. Click
Paern.
3. Select a paern.
4. Click Record.
5. Use direcon buons to wheel the camera to required locaons. Adjust zoom and focus as your
desire.
6. Click Stop Recording. The previous PTZ camera moving path is recorded as a
paern.
Network Video Recorder User Manual
9

HIKVISION DS-7104NI-Q1 Specifications

General

Certification	FCC 15 B, ANSI C63.4-2014 CE EN50130-4, EN 61000-3-2, EN 61000-3-3
Product color	Black
Output current	1 A
Output voltage	48 V
Power consumption (typical)	10 W
Total Power over Ethernet (PoE) budget	36 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
HDD capacity	0 GB
HDD interface	SATA, SATA II, SATA III
Maximum storage capacity	6 TB
Number of HDDs installed	0
Number of HDDs supported	1
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Power over Ethernet (PoE)	Yes
Ethernet LAN (RJ-45) ports	5
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP
Power over Ethernet (PoE) ports quantity	4
Video codecs	H.265+/H.265/ H.264+/H.264
Input bandwidth	40 Mbit/s
Output bandwidth	60 Mbit/s
Maximum resolution	1920 x 1080 pixels
Video input channels	4 channels
Supported resolutions	1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Wi-Fi	No

Weight and Dimensions

Depth	225 mm
Width	265 mm
Height	48 mm
Weight	1000 g
