103
Appendix D Specifications
Model DS-7108HI
Compression standard H.264
Preview resolution PAL:704*576(4CIF) NTSC704*480(4CIF)
Recording resolution PAL:352*288(CIF) NTSC352*288(CIF)
Video input 8 channels BNC ( 1.0 Vp-p ,75 Ohm)
Video out 1 channel BNC (1.0Vp-p ,75 Ohm)
Video spot out 1 channel BNC (1.0Vp-p , 75 Ohm)
Frame rate PAL: 15FPS, NTSC: 20FPS
Audio compression standard OggVorbis 16Kbps
Audio in 4 channels RCA (2 Vp-p ,1KOhm)
Audio out 1 channels RCA (Linear electrical level,
1KOhm)
Stream type Video or Video&Audio
Bit rate 32Kbps-2Mbps (self definition) recommend
768Kbps each channel
IDE interface 1 IDE interface , support 2 HDDs
Network port 10M/100M self-adapt Ethernet port
RS-232 port 1
RS485 port T+T- R+R-
USB 1 USB 2.0 interface ,support USB disk, USB
HDD, USB CD/DVD-R/W
VGA No 1VGA
Resolution:
800*600/60Hz
1024*768/60Hz
1280*1024/60Hz
Alarm in 16 channels
Alarm out 4 channels
Power supply DC 12V
Power consumption 10W（without HDD）
Working temperature -10℃--+55℃
Working humidity 10%-90%
Dimension 445mm*290mm*44mm
PAL: 176*144(QCIF), 352*288(CIF), 704*288(2CIF), 528*384(DCIF), 704*576(4CIF);
NTSC: 176*120(QCIF), 352*240(CIF), 704*240(2CIF), 528*320(DCIF), 704*480(4CIF).
