HIKVISION DS-7208HGHI-F1 User Manual

Digital Video Recorder User Manual
183

Please refer to the Chapter 10.4 Intrusion Detection for operating steps to configure the fast
moving detection.

The Sensitivity in the Rule Settings defines the moving speed of the object which can
trigger the alarm. The higher the value is, the more easily a moving object can trigger the
alarm.

Up to 4 rules can be configured.
10.10 Parking Detection
Purpose
Parking detection function detects illegal parking in places such as highway, one-way street, etc.,
and a series of actions can be taken when the alarm is triggered.

Please refer to the Chapter 10.4 Intrusion Detection for operating steps to configure the
parking detection.

The Threshold [5s-20s] in the Rule Settings defines the time of the vehicle parking in the
region. If you set the value as 10, alarm is triggered after the vehicle stay in the region for
10s.

Up to 4 rules can be configured.
10.11 Unattended Baggage Detection
Purpose
Unattended baggage detection function detects the objects left over in the pre-defined region
such as the baggage, purse, dangerous materials, etc., and a series of actions can be taken when
the alarm is triggered.

HIKVISION DS-7208HGHI-F1 Specifications

General

Product color	Black
Rack capacity	1U
Channels quantity	8 channels
Remote control type	128
Video capturing speed	30 fps
Audio formats supported	G.711
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+
Playback resolutions supported	1080p lite
BNC input ports	8
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	12 W
Storage temperature (T-T)	10 - 90 °C
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Weight	1000 g
Dimensions (WxDxH)	260 x 222 x 45 mm
