User Manual of Digital Video Recorder
69
Figure 4. 5 PTZ Settings
2.
Select patrol No. in the drop-down list of patrol.
3.
Click the
Set
button to add key points for the patrol.
Figure 4. 6 Key point Configuration
4.
Configure key point parameters, such as the key point No., duration of staying for one key point and speed
of patrol. The key point is corresponding to the preset. The
Key Point No.
determines the order at which
the PTZ will follow while cycling through the patrol. The
Duration
refers to the time span to stay at the
corresponding key point. The
Speed
defines the speed at which the PTZ will move from one key point to
the next.
5.
Click the
Add
button to add the next key point to the patrol, or you can click the
OK
button to save the
key point to the patrol.
You can delete all the key points by clicking the
Clear
button for the selected patrol, or click the
Clear
All
button to delete all the key pints for all patrols.
4.2.4
Calling Patrols
Purpose:
Calling a patrol makes the PTZ to move according the predefined patrol path.
Steps:
1.
Click the button
PTZ
in the lower-right corner of the PTZ setting interface;
Or press the PTZ button on the front panel or click the PTZ Control icon in the quick setting bar, or
select the PTZ option in the right-click menu to show the PTZ control panel.
