User Manual of Network Video Recorder
186
5. You can click Array tab to view the information of the successfully created array.
By default, one-touch configuration creates an array and a virtual disk.
Figure 12. 4 Array Settings Interface
6. Click Virtual Disk tab to view the automatically created virtual disk.
By default, one-touch configuration adopts background initialization to initialize the virtual disk, thus
the virtual disk can be used immediately.
Figure 12. 5 Virtual Disk Settings Interface
7. You can see the information of the logical disk in the HDD Information interface.
For configuring hot spare disk manually, please refer to steps 12-15 of Chapter 10.1.2.
12.1.2 Manually Creating Array and Virtual Disk
Purpose:
You can manually create the array of RAID 0, RAID 1, RAID 5 and RAID 10.
In this section, we take RAID 5 as an example to describe the manual configuration of array and virtual disk.
Steps:
1. Enter the Physical Disk Settings interface.
Menu > HDD > RAID > Physical Disk
To Next Page
