User Manual of Network Video Recorder
206
Figure 13. 12 Array Settings Interface
If there is no hot spare disk after rebuilding, it is recommended to install a HDD into the device and set is as a hot
spare disk to ensure the high security and reliability of the array.
13.2.2 Manually Rebuilding Array
Purpose:
If you do not enable the Auto-rebuild in Firmware Settings interface (Menu>HDD>RAID>Firmware) or the hot
spare disk has not been configured, then you can rebuild the array manually to restore the array when the virtual
disk is in Degraded status.
Steps:
1. Enter the Array Settings interface. The disk 3 is lost.
Menu > HDD > RAID > Array
Figure 13. 13 Array Settings Interface
2. Click Array tab to back to the Array Settings interface and click to configure the array rebuild.
At least one available physical disk should exist for rebuilding the array.
Figure 13. 14 Rebuild Array Interface
3. Select the available physical disk and click OK button to confirm to rebuild the array.
4. The “Do not unplug the physical disk when it is under rebuilding” message box pops up. Click OK button to
