Video Intercom Indoor Station·User Manual
89
10.4.5 Calling Management Center and Calling Elevator
Purpose:
You can call elevator and call management center from the indoor station/extension.
Calling Management Center
Steps:
1. Press the tab to enter the contact list interface, or press the tab to
enter the live view interface.
2. Press the tab.
 Center here refers to the master station and iVMS-4200 client.
 You also can call management center successfully by pressing the
tab directly.
 For indoor extension, press the tab directly on the user interface to
call the management center.
Calling Elevator
Steps:
1. Press the tab to enter the contact list interface
2. Press the tab.
 You also can call the elevator successfully by pressing the tab
directly.
 For indoor extension, press the tab directly on the user interface
to call the elevator.

HIKVISION DS-KH8301-WT Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Proper use	Indoor
Control type	Touch
Product color	White
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Outdoor unit included	No
Operating system installed	Linux
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Megapixel	0.3 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
