26
Specifications
Model Name LE42EC06AU LE47EC06AU LE55EC06AU
Panel Size Approx. 42 inches Approx. 47 inches Approx. 55 inches
Resolution 1920
x
1080 1920
x
1080 1920
x
1080
Power Requirement AC 100-240V, 50/60Hz AC 100-240V, 50/60Hz AC 100-240V, 50/60Hz
Terminals /
Input Signals
Analogue
PAL BG, DK, I
SECAM DK
(44.25MHz ~ 863.25MHz)
Digital
DVB-T (177.5MHz ~ 816.5MHz)
AV IN
PAL, SECAM, NTSC
COMPONENT IN
YPBPR
480i/p, 576i/p, 720p(50/60), 1080i(50/60), 1080p(50/60)
HDMI1 IN,
HDMI2 IN,
HDMI3 IN
HDMI4 IN
480i/p, 576i/p, 720p(50/60), 1080i(50/60), 1080p(24/50/60)
RGB IN
(Analogue)
640x480(60), 800x600(60), 1024x768(60), 1280x1024(60)
USB 1
USB 2
USB Port
AUDIO IN Diameter 3.5mm Mini Jack
Terminals /
Output
Signals
S/PDIF Digital Audio Output (Coaxial)
Headphones Diameter 3.5mm Mini Jack
Supplied
Accessories
User Manual (
x
1)
Product Warranty Info Sheet (
x
1)
Remote Control (
x
1)
AA Battery (
x
2)
Stand (
x
1)
USB Extension Cable (
x
1)
Passive 3D Glasses (x 2)
• Design and specifications are subject to change without notice.
• Weight and dimensions shown are approximate values only.
RGB Input Signal Chart
Resolution
Vertical
Frequency (Hz)
Horizontal
Frequency (kHz)
Dot Clock
Frequency (MHz)
VGA 640 x 480 60 31.47 25.18
SVGA 800 x 600 60 37.88 40.00
XGA 1024 x 768 60 48.36 65.00
SXGA 1280 x 1024 60 63.98 108.00
WXGA 1280 x 768 60 47.78 79.50
• If the message “Unsupported Signal” appears on the screen, adjust the PC display setting as in the above chart.
• Modes that are not listed in the above chart may not be supported. For an optimal picture, it is recommended to
choose a mode listed in the chart.
• Sometimes, the image may be disrupted due to the frequency standard from the VGA card. This is not an error.
You may improve this situation by selecting “Auto Adjust” or adjusting the position, phase and clock settings in the
RGB Mode Setup menu manually.
• If you switch off the TV, interference lines may occur on the TV screen. This is normal.
