10.3.2 Wire size and Main switch protection
Model Power supply
Power source cable size Transmitting cable size
MC
(A)
CB
(A)
ELB
(nº poles/A/mA)
EN60 335-1 EN60 335-1
RAS-2WHVRP
2
2
RAS-2.5WHVRP
2
RAS-3WHVRP
2
? NOTE
• ELB: Earth switch; CB: Circuit breaker
• Follow local codes and regulations when selecting eld wires, Circuit breakers and Earth Leakage breakers.
• Use the wires which are not lighter than the ordinary polychloroprene sheathed exible cord (code designation 60245 IEC 57).
11 COMMISSIONING
? CAUTION
Do not operate the system until all the check points have been cleared:
• Check to ensure that the electrical resistance is more than 1 MΩ, by
measuring the resistance between ground and the terminal of the
electrical parts. If not, do not operate the system until the electrical
leakage is found and repaired. Do not impress the voltage on the
terminals for transmission 1 and 2.
• Check to ensure that the stop valves of the outdoor unit are fully
opened, and then start the system.
• Check to ensure that the switch on the main power source has been
ON for more than 12 hours, to warm the compressor oil by the oil
heater.
• Pay attention to the following items while the system is running:
• Do not touch any of the parts by hand at the discharge gas side,
since the compressor chamber and the pipes at the discharge side
are heated higher than 90°C.
• DO NOT PUSH THE BUTTON OF THE MAGNETIC SWITCH(ES), it
will cause a serious accident.
• Do not touch any electrical components for more than three minutes
after turning OFF the main switch.
• Conrm that the gas line stop valve and the liquid line stop valve are
fully open.
• Conrm that the leakage of the refrigerant does not exist. The are
nuts are sometimes loosened by vibration during transportation.
• Check that the refrigerant piping and the electrical wiring conform to
the same system.
• Conrm that the dip switch setting on the printed circuit board of the
indoor units and the outdoor units are correct.
• Check whether or not the electrical wiring of the indoor units and the
outdoor units are connected properly.
12 MAIN SAFETY DEVICES
Compressor Protection
Fan Motor Protection
Model
RAS-2WHVRP
RAS-2.5WHVRP
RAS-3WHVRP
-
-
A
-
3
-
A 5
PMML0509 rev.0 - 02/2019
