Honda 2004 XR400R User Manual

(1)
(2)
(3)
(1) wheel rim
(2) spoke
(3) rim lock
REAR
112
Wheel Rims & Spokes
Wheels
Servicing Your Honda
Saf ety PrecautionsRefer to on page .
Maintenance of spoke tension and wheel
trueness (roundness) is critical to safe
motorcycle operation. During the first 100
miles (150 km), spokes will loosen more
rapidly due to the initial seating of the parts.
Excessively loose spokes may result in
instability at high speeds and the possible loss
of control. It’s also important that the rim locks
are secure to prevent tire slippage.
It is not necessary to remove the wheels to
perform the recommended service in the
Maintenance Schedule. However, information
for wheel removal is provided for emergency
situations.
Inspect the wheel rims ( ) and spokes ( )
for damage.
Tighten any loose spokes or rim locks ( ).
12
3
1.
2.
45
03/05/20 10:13:33 31KCY680_121

Honda 2004 XR400R Specifications

General

Displacement	397 cc
Cooling System	Air-cooled
Bore x Stroke	85.0 mm x 70.0 mm
Compression Ratio	9.3:1
Transmission	5-speed
Front Brake	Single disc
Rear Brake	Single disc
Ignition	CDI
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	Air-cooled 4-stroke single cylinder
Front Suspension	43mm telescopic fork
Rear Suspension	Pro-Link single shock
Induction	Carburetor
Ground Clearance	12.4 inches
