Honda 2004 XR400R User Manual

(1) side stand spring
(1)
LEFT SIDE
122
Side Stand
Servicing Your Honda
Saf ety PrecautionsRefer to on page . Check the side stand spring ( ) for damage
and loss of tension.
Check the side stand assembly for freedom
of movement.
If the side stand is stiff or squeaky, clean the
pivot area and lubricate the pivot bolt with
clean engine oil.
1.
2.
145
03/05/20 10:15:12 31KCY680_131

Honda 2004 XR400R Specifications

General

Displacement	397 cc
Cooling System	Air-cooled
Bore x Stroke	85.0 mm x 70.0 mm
Compression Ratio	9.3:1
Transmission	5-speed
Front Brake	Single disc
Rear Brake	Single disc
Ignition	CDI
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	Air-cooled 4-stroke single cylinder
Front Suspension	43mm telescopic fork
Rear Suspension	Pro-Link single shock
Induction	Carburetor
Ground Clearance	12.4 inches
