9. CYLINDER HEAD/VALVES/OIL PUMP
1. CYLINDER HEAD COVER
REMOVAL ........................................... 9-2
2. CYLINDER HEAD ASSEMBLY
REMOVAL ........................................... 9-4
3. CYLINDER HEAD ASSEMBLY
DISASSEMBLY.................................... 9-6
4. INSPECTION...................................... 9-13
5. VALVE GUIDE REPLACEMENT ....... 9-19
6. VALVE SEAT RECONDITIONING .... 9-21
7. CYLINDER HEAD ASSEMBLY
REASSEMBLY ................................... 9-23
8. CYLINDER HEAD ASSEMBLY
INSTALLATION ................................. 9-29
9. CYLINDER HEAD COVER
INSTALLATION ................................. 9-31
10. OIL PUMP.......................................... 9-34
