Honda BF90D User Manual

174 pages

To Next Page

To Next Page

Page #1 background image

Table of Contents

Default Chapter6
- Table of Contents6
1 Safety9
- Safety Information9
2 Safety Label Locations12
3 Component Identification15
4 Controls and Features23
- Engine Switch (Ignition Switch)23
- Shift Lever23
- Throttle Grip24
- Throttle Friction Adjuster24
- Emergency Stop Switch25
- Emergency Stop Switch Lanyard/Clip25
- Steering Friction Adjusting Knob26
- Remote Control Lever27
5 Installation50
- Transom Height50
- Location51
- Installation Height51
- Outboard Motor Installation52
- Outboard Motor Angle Inspection (Cruising)53
  - Outboard Motor Angle Adjustment (G Type)54
- Battery Connections55
- Remote Control Installation (Equipped Type or Optional Equipment)57
  - Remote Control Box Location58
  - Remote Control Cable Length58
- Propeller Selection59
6 Pre-Operation Checks60
- Engine Cover Removal/Installation60
- Engine Oil60
- Fuel63
- Gasoline Containing Alcohol64
- Propeller and Cotter Pin Inspection65
- Tiller Handle Height/Angle Adjustment (H Type)66
- Steering Handle Friction (H Type)67
- Remote Control Lever Friction67
- Water Separator68
- Battery68
- Other Checks70
7 Starting the Engine71
- Fuel Line Connection71
- Fuel Priming73
- Starting the Engine74
  - H Type74
  - R Type77
    - R1 Type77
    - R2, R3 Types81
- Emergency Starting85
8 Operation91
- Break-In Procedure91
- Gear Shifting92
- Steering96
- H Type96
  - R Type96
- Cruising97
  - H Type97
  - R Type99
- TRL (Trolling) Control Switch101
  - (Optional Equipment: R Type)101
- Trimming the Outboard Motor102
- Trim Meter (Equipped Type or Optional Equipment)105
- Tilting the Outboard Motor106
  - G Type106
  - T Type107
- Moorage108
  - G Type108
  - T Type109
- Power Tilt Switch (T Type)110
- Manual Relief Valve (T Type)111
- Trim Tab Adjustment112
- Engine Protection System113
- Shallow Water Operation117
- Multiple Outboard Motors118
9 Stopping the Engine119
- Emergency Engine Stop119
- Normal Engine Stop120
  - H Type120
  - R Type121
10 Transporting122
- Fuel Line Disconnection122
- Trailering123
11 Cleaning and Flushing124
12 Maintenance125
- Tool Kit and Emergency Parts126
- Maintenance Schedule127
- Engine Oil129
- Spark Plugs131
- Battery135
- Lubrication137
- Water Separator139
- Fuel Filter142
- Fuel Tank and Tank Filter (Equipped Type)144
- Emission Control System145
- Fuse146
- ACG Fuse147
- Propeller148
- Inspect after Operating149
- Submerged Outboard Motor149
13 Storage150
- Fuel150
- Vapor Separator Draining151
- Battery Storage152
- Outboard Motor Position153
14 Disposal154
15 Troubleshooting155
16 Specifications157
17 MAJOR Honda DISTRIBUTOR ADDRESSES162
18 Ec Declaration of Conformity'' Content Outline165
19 Index170
