Honda BF90D User Manual

24
CONTROLS AND FEATURES (H type)
Emergency Stop Switch
Press the emergency stop switch to
stop the engine.
The emergency stop switch lanyard is
provided to stop the engine
immediately when the operator falls
overboard or away from the outboard
motor.
The engine stops when the clip at the
end of the emergency stop switch
lanyard is pulled out of the
emergency stop switch.
When operating the outboard motor,
be sure to attach one end of the
emergency stop switch lanyard
securely to the operator.
If the emergency stop switch
lanyard is not set, the boat might
run out of control when the
operator, for example, falls
overboard and is not able to
operate the outboard motor.
For the sake of the operator’s and the
passengers’ safety, be sure to set the
emergency stop switch clip located at
one end of the emergency stop switch
lanyard with the emergency stop
switch. Attach the other end of the
emergency stop switch lanyard
securely to the operator.
EMERGENCY STOP SWITCH
STOP
E
S
Emergency Stop Switch Lanyard/Clip
EMERGENCY STOP
SWITCH
STOP
EMERGENCY STOP
SWITCH CLIP
EMERGENCY STOP
SWITCH LANYARD
EMERGENCY STOP
SWITCH CLIP
EMERGENCY
STOP SWITCH
LANYARD
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
