Tilting the Motor
OPERATION
POWER TRIM/TILT SWITCH
POWER TRIM/TILT SWITCH
POWER TRIM/TILT SWITCH
(single type)
POWER TRIM/TILT SWITCH
(LEFT) (RIGHT)
POWER TRIM/TILT
SWITCH
(R3 type)(R1 type)
(R2 type)
(dual type)
(H type)
Tilt the motor to prevent the
propeller and gear case from hitting
the bottom when the boat is beached
or stopped in shallow water.
Please tilt up simultaneously, when
you mount the dual type outboard
motor.
Move the remote control lever to
the NEUTRAL position and stop
the engine.
Press the UP of the power trim/tilt
switch and tilt the motor to the best
position in compliance.
1.
2.
