4. CONTROLS AND FEATURES (H type)
This tiller handle is equipped with an
automotive type ignition switch.
Key positions:
Do not leave the engine switch
(ignition switch) ON (key in ON
position) when the engine is not
running as the battery will
discharge.
The starter motor will not work
unless the shift lever is in the
NEUTRAL position.
Use the shift lever to run the boat in
forward or reverse gear, or to cut off
the engine power from the propeller.
There are three positions for the shift
lever.
FORWARD:
NEUTRAL:
REVERSE:
START: to start the engine.
ON: to run the engine after
starting.
OFF: to stop the engine
(IGNITION OFF).
········
···
···
Shift Lever
NEUTRAL
REVERSEFORWARD
NEUTRAL
REVERSE
FORWARD
SHIFT
LEVER
The boat movesahead.
The engine power is
cut off from the
propeller. The boat
does not move.
The boat reverses.
····
····
····
····
ON
START
ON
OFF
OFFSTART
ENGINE SWITCH
(IGNITION SWITCH)
NEUTRAL
SHIFT LEVER
NEUTRAL
Engine Switch (Ignition Switch)
