STARTING THE ENGINE
Starting the Engine
The exhaust contains poisonous
carbon monoxide.
Do not start the engine in a poor
ventilation area such as in a boat
house.
To prevent damage to the outboard
from overheating, never run the
engine with the propeller out of
water.
When the boat is mounted with two
outboard motors, perform the
following on the right and left
engines respectively.
1. Insert the clip at one end of the
emergency stop switch lanyard into
the emergency stop switch.
Attach the other end of the
emergency stop switch lanyard
securely to the operator.
Be sure to install the emergency
stop switch clip to the emergency
stop switch on the remote control
box as well as on the control panel.
If the operator does not attach the
emergency stop switch lanyard,
and is thrown from his seat or out
of the boat, the out-of-control boat
can seriously injure the operator,
passengers, or bystanders. Always
properly attach the lanyard before
starting the engine.
The engine does not start unless the
clip is set on the emergency stop
switch.
Store the spare emergency stop
switch clip in the tool bag.
(R2, R3 types)
EMERGENCY
STOP SWITCH
EMERGENCY STOP
SWITCH CLIP
CONTROL PANEL
STOP
EMERGENCY
STOP SWITCH
LANYARD
SPARE EMERGENCY
STOP SWITCH CLIP
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
