Honda BF90D User Manual

119
STOPPING THE ENGINE
1. Turn the throttle grip to SLOW
position and move the shift lever to
NEUTRAL.
After sailing with the throttle fully
open, cool down the engine by
running it at the idle speed for a few
minutes.
2. Turn the engine switch key to the
OFF position to stop the engine.
In the event that the engine does not
stop when the engine switch is turned
to OFF, push the emergency stop
switch to stop the engine.
3. Remove the engine switch key and
store it.
If you are using a portable fuel
tank, disconnect the fuel line if you
will be storing or transporting the
outboard motor.
·····
ENGINE SWITCH KEY
OFF
OFF
·····
·····
THROTTLE
GRIP
SLOW
SLOW
SHIFT
LEVER
NEUTRAL
NEUTRAL
Normal Engine Stop
(H type)
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
