Honda BF90D User Manual

122
TRANSPORTING
3. Secure the outboard motor on an
outboard motor stand with the
mounting bolts and nuts.
4. Remove the hoist hook and
reinstall the engine cover.
Trailering
(H type)
When trailering or transporting the
boat with the outboard motor attached
always disconnect the fuel line from
the portable fuel tank and tighten the
steering friction adjusting knob
securely (see page 66).
(R type)
When trailering or transporting the
boat with the outboard motor
attached, it is recommended that the
outboard motor remain in normal
running position.
Do not trailer or transport the boat
with the outboard motor in the
tilted position. The boat or
outboard motor could be severely
damaged if the outboard motor
drops.
The outboard motor should be
trailered in the normal running
position. If there is insufficient road
clearance in this position, then trailer
the outboard motor in the tilted
position using an outboard motor
support device such as a transom
saver bar, or remove the outboard
motor from the boat.
OUTBOARD MOTOR STAND
STEERING FRICTION
ADJUSTING KNOB
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
