Honda BF90D User Manual

69
PRE-OPERATION CHECKS
Check the following items:
(1) The fuel hose for kinking,
collapsing or a loose connection.
(2) The tiller handle for loose
installation, wobble or smooth
operation (H type).
The remote control lever for
smooth operation (R type).
(3) The switch for correct operation.
(4) The stern bracket for damage.
(5) The tool kit for missing spare
parts and tools (see page 125).
(6) The anode metal for damage,
looseness or excessive corrosion.
The anode (sacrificed metal) helps to
protect the outboard motor from
corrosion damage; it must be exposed
directly to the water whenever the
outboard motor is in use. Replace the
anodes when they have been reduced
to about two-thirds of their original
size, or if they are crumbling.
The possibility of corrosion damage
is increased if the anode is painted
over or allowed to deteriorate.
Parts/materials which should be
installed on board:
• Owner’s Manual
•Tool kit
• Spare parts: spark plugs, engine oil,
spare propeller, castle nut, washer
and cotter pin.
• Spare emergency stop switch clip
• Other parts/materials required by
laws/regulations.
Other Checks
(5) TOOL KIT (see page 125)
(6)
(4)
(3)
(2)
(3)
(2)
(1)
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
