109
OPERATION
(R3 type) (DUAL TYPE)
After tilting down the outboard
motors, adjust the trim angle of the
right and left outboard motors.
Power Tilt Switch (T type)
When you are away from the power
trim/tilt switch on the control lever
side or the tiller handle side, you can
operate the power tilt switch on the
outboard motor side.
The switch operation is the same as
that of the power trim/tilt switch.
Do not operate this power tilt
switch on the outboard motor while
sailing.
POWER TRIM/TILT SWITCH
(LEFT) (RIGHT)
POWER TILT SWITCH
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
