Honda BF90D User Manual

152
STORAGE
3. Fill the battery with distilled water
to the upper level line. Never
overfill the battery.
4. Store the battery on a level surface
in a cool, dry, well ventilated place
out of direct sunlight.
5. Once a month, check the specific
gravity of the electrolyte and
recharge as required to prolong
battery life.
Outboard Motor Position
Transport and store the outboard
motor either vertically, as shown
above. Attach the stern bracket to
stand and secure the outboard motor
with bolts and nuts. Store the
outboard motor in a well-ventilated
area free from direct sunlight and
humidity.
Do not place the outboard motor on
its side during a prolonged period
of storage. If you are obliged to
place the outboard motor on its
side, drain the engine oil, protect
the outboard motor by wrapping it
with the urethane material or the
blanket as shown.
OUTBOARD MOTOR STAND
(Port side turned down as shown.)
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
