Honda BF90D User Manual

72
STARTING THE ENGINE
Fuel Priming
Hold the priming bulb so that the
outlet end is higher than the inlet (so
that the arrow on the priming bulb
points up), and squeeze it until it feels
firm, indicating that fuel has reached
the outboard motor. Check for leaks.
Be careful not to spill any fuel.
Spilled fuel vapor may ignite. If
any fuel is spilled, make sure the
area is dry before starting the
engine.
Do not touch the priming bulb with
the engine running or when tilting
up the outboard motor. The vapor
separator could overflow.
ARROW
OUTLET END
(outboard
motor side)
PRIMING BULB
INLET END 
(tank side)
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
