Honda BF90D - Page 77

−
−
76
If the engine is not properly
warmed-up before raising the
engine speed, the warning buzzer
and overheat indicator may
activateandtheenginespeedwill
be automatically reduced.
STARTING THE ENGINE
NORMAL: ON
ABNORMAL: OFF
ENGINE OIL PRESSURE
INDICATOR
Normal
Abnormal
DIGITAL TACHOMETER
Before leaving the dock, check the
operation of the emergency stop
switch.
Check to see if the oil pressure
indicator turns ON.
If the oil level is normal and the oil
pressure indicator light does not
turn ON, consult with an
authorized Honda outboard motor
dealer.
Check the oil level (see page ).
If it does not turn on, stop the engine
and perform the following
inspections.
Warm up the engine as follows:
Below 5°C (41°F) run the engine
for at least 5 minutes at approx.
2,000 min (rpm).
Failure to completely warm up the
engine will result in poor engine
performance.
Above 5°C (41°F) run the engine
for at least 3 minutes.
2)
1)
5.
6.
53
