Honda BF90D User Manual

66
PRE-OPERATION CHECKS
Steering Handle Friction (H type)
Check whether the handle moves
smoothly.
For smooth steering, adjust the
steering friction adjusting knob so
that a slight drag is felt when turning.
Remote Control Lever Friction
(R1 type)
Check whether the remote control
lever moves smoothly.
Friction of the control lever can be
adjusted by turning the control lever
friction adjuster right or left.
(R2 type)
(R3 type)
STEERING FRICTION
ADJUSTING KNOB
To decre ase
friction
To increase
friction
CONTROL LEVER
FRICTION ADJUSTER
To decre ase
friction
To increase
friction
CONTROL LEVER
FRICTION ADJUSTER
To decrease
friction
To incre ase
friction
CONTROL LEVER
FRICTION ADJUSTER
To decrease
friction
To increase
friction
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
