94
OPERATION
Avoid sharp and abrupt operation
of the control lever. Operate it
moderately. Operate the control
lever and raise the engine speed
after making sure that the gear was
shifted securely.
Move the control lever(s)
approximately 35° toward the
FORWARD or REVERSE position to
engage the desired gear.
When the boat is mounted with the
two outboard motors, hold the control
lever in the center as shown, and
operate the right and left levers
simultaneously.
Moving the control lever(s) further
from approximately 35° will increase
throttle opening and boat speed.
Gear Shifting
(R3 type)
REMOTE CONTROL
LEVER
(SINGLE TYPE) (DUAL TYPE)
REMOTE CONTROL LEVERS
REMOTE
CONTROL
LEVER
REVERSE
NEUTRAL
FORWARD
NEUTRAL
FORWARD
REVERSE
<;DQQMࡍ࡯ࠫ㧞㧜㧝㧟ᐕ㧝㧜᦬㧝㧤ᣣޓ㊄ᦐᣣޓඦᓟ㧞ᤨ㧟㧟ಽ

Honda BF90D Specifications

General

Bore & Stroke	73 mm x 89.4 mm
Horsepower	90 HP
Cooling System	Water Cooled
Starting System	Electric
Gear Ratio	2.33:1
Trim Range	-4° to +16°
Tilt Range	70°
Dry Weight	163 kg (359 lbs)
Lubrication	Wet Sump
Recommended Fuel	Unleaded Gasoline (86 Octane or higher)
Gear Shift	F-N-R
Steering	Remote
Trim Method	Power Trim and Tilt
Displacement	1496 cc
Exhaust	Through propeller
Alternator Output	44 Amps
Recommended Engine Oil	10W-30 FC-W
Shaft Length	20" or 25"
Engine Type	4-Stroke SOHC, 4 Cylinders
Fuel Delivery	Programmed Fuel Injection
