Honda CBR1000RR Owner's Manual

Keys
132
Information
Keys
This motorcycle has two ignition keys and a key
tag with a key number and a bar code.
The ignition key contains a special coded chip
that is recognized by the immobilizer system
(HISS) in order to start the engine. Handle the
key carefully to prevent damaging the HISS
components.
● Do not bend keys or subject them to undue
stress.
● Avoid prolonged exposure to sunlight or high
temperatures.
● Do not grind, drill or in any way alter their
shape.
● Do not expose to strong magnetic objects.
If you lose all keys and the key tag, the PGM-FI
unit/ignition control module must be replaced
by your dealer. To avoid this, keep a duplicate
key.
If you lose a key, make another duplicate key
immediately.
To make a duplicate key and register it with
your HISS system, take the spare key, the key
tag, and the motorcycle to your dealer.
u Store the tag in a safe location.
A metal key holder may cause damage to the
area surrounding the ignition switch.
Ignition key
Ignition key
Key tag
Key number and bar code
14 CBR1000RR S-32MGP6110.book 132 ページ ２０１３年１１月２９日 金曜日 午前９時２７分

Honda CBR1000RR Specifications

General

Engine Type	Liquid-cooled 4-stroke 16-valve DOHC inline-4
Displacement	999cc
Compression Ratio	13.0:1
Transmission	6-speed
Ignition	Computer-controlled digital transistorized with electronic advance
Bore x Stroke	76 mm x 55.1 mm
Fuel System	PGM-DSFI (Programmed Dual Sequential Fuel Injection)
Front Suspension	43 mm inverted telescopic fork with Big Piston Front Fork (BPF), spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link with gas-charged HMAS damper, spring preload and rebound damping adjustability
Front Brakes	Dual 320 mm hydraulic discs with radial-mount 4-piston calipers
Rear Brakes	Single 220 mm hydraulic disc with single-piston caliper
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Wheelbase	1, 405 mm (55.3 in)
Max Power	189 hp @ 13, 000 rpm
Max Torque	114 Nm @ 11, 000 rpm
