Honda CBR1000RR Owner's Manual

86
Maintenance
Brakes
Checking Brake Fluid
1. Place your motorcycle in an upright
position on a firm, level surface.
2. Check that the brake fluid reservoir is
horizontal and that the fluid level is
between the LOWER level and UPPER level
marks.
If the brake fluid level in either reservoir is
below the LOWER level mark or the brake
lever and pedal freeplay becomes excessive,
inspect the brake pads for wear. If the brake
pads are not worn, you most likely have a
leak. Have your motorcycle inspected by your
dealer.
Front
Rear
Front brake fluid reservoir
LOWER level mark
Rear brake fluid reservoir
UPPER level mark
LOWER level mark
UPPER level mark
14 CBR1000RR S-32MGP6110.book 86 ページ ２０１３年１１月２９日 金曜日 午前９時２７分

Honda CBR1000RR Specifications

General

Engine Type	Liquid-cooled 4-stroke 16-valve DOHC inline-4
Displacement	999cc
Compression Ratio	13.0:1
Transmission	6-speed
Ignition	Computer-controlled digital transistorized with electronic advance
Bore x Stroke	76 mm x 55.1 mm
Fuel System	PGM-DSFI (Programmed Dual Sequential Fuel Injection)
Front Suspension	43 mm inverted telescopic fork with Big Piston Front Fork (BPF), spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link with gas-charged HMAS damper, spring preload and rebound damping adjustability
Front Brakes	Dual 320 mm hydraulic discs with radial-mount 4-piston calipers
Rear Brakes	Single 220 mm hydraulic disc with single-piston caliper
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Wheelbase	1, 405 mm (55.3 in)
Max Power	189 hp @ 13, 000 rpm
Max Torque	114 Nm @ 11, 000 rpm
