Honda CBR1000RR Owner's Manual

Coolant u Adding Coolant
85
Maintenance
Adding Coolant
If the coolant level is below the lower level,
add the recommended coolant (2 P. 68) until
the level reaches the upper level mark.
Add fluid only from the reserve tank cap and
do not remove radiator cap.
1. Remove the reserve tank cap and add
fluid while monitoring the coolant level.
u Do not overfill above the upper level
mark.
u Make sure no foreign objects enter the
reserve tank opening.
2. Securely reinstall the cap.
Changing Coolant
Have your dealer change the coolant unless
you have the proper tools and are
mechanically qualified.
3 WARNING
Removing the radiator cap while the
engine is hot can cause the coolant to
spray out, potentially scalding you.
Always let the engine and radiator
cool down before removing the
radiator cap.
14 CBR1000RR S-32MGP6110.book 85 ページ ２０１３年１１月２９日 金曜日 午前９時２７分

Honda CBR1000RR Specifications

General

Engine Type	Liquid-cooled 4-stroke 16-valve DOHC inline-4
Displacement	999cc
Compression Ratio	13.0:1
Transmission	6-speed
Ignition	Computer-controlled digital transistorized with electronic advance
Bore x Stroke	76 mm x 55.1 mm
Fuel System	PGM-DSFI (Programmed Dual Sequential Fuel Injection)
Front Suspension	43 mm inverted telescopic fork with Big Piston Front Fork (BPF), spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link with gas-charged HMAS damper, spring preload and rebound damping adjustability
Front Brakes	Dual 320 mm hydraulic discs with radial-mount 4-piston calipers
Rear Brakes	Single 220 mm hydraulic disc with single-piston caliper
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Wheelbase	1, 405 mm (55.3 in)
Max Power	189 hp @ 13, 000 rpm
Max Torque	114 Nm @ 11, 000 rpm
