Honda CBR1000RR Owner's Manual

146
Specifications
Specifications
Specifications
■ Main Components
*1 Including rider, passenger, all luggage, and accessories
*2 Including rider, all luggage, and accessories
Type SC59
Overall length 2,075 mm (81.7 in)
Overall width 720 mm (28.3 in)
Overall height 1,135 mm (44.7 in)
Wheelbase 1,410 mm (55.5 in)
Minimum ground
clearance
130 mm (5.1 in)
Caster angle 23º 18´
Trail
Except KO, III KO type 96.0 mm (3.78 in)
KO, III KO type 95.9 mm (3.78 in)
Curb weight
CBR1000RR 200 kg (441 lb)
CBR1000RA 211 kg (465 lb)
CBR1000S 199 kg (439 lb)
CBR1000SA 210 kg (463 lb)
Maximum weight
capacity
CBR1000RR/RA*
1
Except KO, III KO type 180 kg (397 lb)
KO, III KO type 160 kg (353 lb)
CBR1000S/SA*
2
110 kg (243 lb)
Maximum luggage
weight
(Except KO type)
CBR1000RR/RA 14 kg (31 lb)
CBR1000S/SA 3 kg (7 lb)
Passenger capacity
CBR1000RR/RA
Rider and 1
passenger
CBR1000S/SA
Rider only
(no passenger)
Minimum turning
radius
3.2 m (10.5 ft)
Displacement 999 cm
3
(60.9 cu-in)
Bore × stroke 76.0 × 55.1 mm (2.99 × 2.17 in)
Compression ratio 12.3:1
Fuel
Unleaded petrol
Recommended: 95 RON or higher
Tank capacity 17.5 litres (4.62 US gal, 3.85 Imp gal)
14 CBR1000RR S-32MGP6110.book 146 ページ ２０１３年１１月２９日 金曜日 午前９時２７分

Honda CBR1000RR Specifications

General

Engine Type	Liquid-cooled 4-stroke 16-valve DOHC inline-4
Displacement	999cc
Compression Ratio	13.0:1
Transmission	6-speed
Ignition	Computer-controlled digital transistorized with electronic advance
Bore x Stroke	76 mm x 55.1 mm
Fuel System	PGM-DSFI (Programmed Dual Sequential Fuel Injection)
Front Suspension	43 mm inverted telescopic fork with Big Piston Front Fork (BPF), spring preload, rebound and compression damping adjustability
Rear Suspension	Unit Pro-Link with gas-charged HMAS damper, spring preload and rebound damping adjustability
Front Brakes	Dual 320 mm hydraulic discs with radial-mount 4-piston calipers
Rear Brakes	Single 220 mm hydraulic disc with single-piston caliper
Front Tire	120/70ZR-17
Rear Tire	190/50ZR-17
Wheelbase	1, 405 mm (55.3 in)
Max Power	189 hp @ 13, 000 rpm
Max Torque	114 Nm @ 11, 000 rpm
